Teltonika Gateway 5G Industrial - 5G Sub-6GHz SA/NSA (Up to 1 Gbps) - Compatible with 4G LTE and 3G networks - 1 Port RJ45 10/100/1000 Mbps - 4 x SMA connectors for mobile antennas - 1 SIM slot Mini SIM - 2FF

SKU: TK-TRB501

5.231.25 kr

Ekskl. moms

Udsolgt

The TK-TRB501 is an ultra-compact industrial gateway designed for environments where minimum latency and massive bandwidth are critical. This device allows 5G technology to be integrated into existing infrastructures immediately, reaching speeds of up to 1 Gbps. Its optimized aluminum design and ability to operate in extreme temperatures (-40 °C to +75 °C) make it the key part for mission critical IoT, telemetry and advanced automation. Thanks to the RutOS ecosystem, the TRB501 not only connects devices, but also protects them with enterprise-grade perimeter security and enables remote 100% management through the RMS platform.

Teltonika
Industrial Gateway TRB501
5G SA/NSA and 4G LTE Cat 20
Port RJ45 10/100/1000 Mbps
1x Input / 1x Digital Output (Configurable)
ARM processor Cortex-A7 1.3 GHz
Rugged aluminum housing
Remote management via RMS

Brand	Teltonika
Device	Industrial Gateway 5G
Ethernet	1 Ethernet port RJ45 10/100/1000 Mbps
CPU	ARM Cortex A7, 1.3 GHz
RAM	512 MB
Flash	512 MB
Type of 5G/4G/3G	5G Sub-6Ghz SA/NSA up to 1Gbps DL / 4G (LTE) - Cat 20
Operating System	RutOS (Based on OpenWrt)
Network Protocols	TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, etc.
VPN Protocols	OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, WireGuard, ZeroTier
Monitoring and Management	WEB UI, CLI, SSH, SMS, TR-069, SNMP, MQTT, RMS
Inputs and Outputs	1 x Digital Input, 1 x Digital Output (on power connector)
Power	DC connector 4 Industrial pins 9~30V
Material	Aluminium
Temp. operation	-40º C ~ +75º C
Dimensions	74.4 x 25 x 64.4 mm
Weight	145 g

Industrial Gateway 5G TRB501
4x Mobile Antenna (SMA Male, swivel)
AC power supply 9W
Ethernet Cable 1,5m
Terminal block kit (I/O)
Quick Start Guide
