JADE BIRD
Jade Bird analog siren - High power output 91 dB(A) @ 1m - Power supply through the loop - Base not included - Indoor installation - Certified EN 54-3
SKU: JBE-2235
656.25 kr
Ekskl. moms
På lager
Jade Bird analog siren - High power output 91 dB(A) @ 1m - Power supply through the loop - Base not included - Indoor installation - Certified EN 54-3
- Jade Bird - Sirena analógica con indicador visual
- High power output 91 dB(A) @ 1m
- Without isolator
- Address programmable by means of the JBE-AT1 tool
- Power supply through the loop
- Indoor installation
- Base not included
- Compatible with base BE-2160 and BE-2165
- Certified EN 54-3
| Brand | Jade Bird |
| Type | Analog siren |
| Operating voltage | DC 19-28,5V |
| Connection | JBE communication bus 2- wires, no polarity |
| Wired | Twisted pair without mesh 0.5 - 2.5 mm² |
| JBE bus consumption | I_max <=10 mA @27V I_average<=6.6 mA @27V; <= 0.18 W @27V |
| Nivel de presión acústica | 91 dBA @1 m; 2.2-3.8kHz Tono barrido (0.5 Hz) |
| Temperatura de trabajo | -10 a +55ºC |
| Temperatura de almacenaje | -20 a +60ºC |
| Entorno | ≤ 95% RH (sin condensación ni formación de hielo) |
| Direccionamiento | Herramienta de direccionamiento JBE-AT1 |
| Rango de dirección | 1-200 |
| Dimensiones (ØxAl) | 100 mm × 52 mm |
| Peso | 0.1 kg (incluida la base) |
| Grado de Protección | IP31 |
| Bases compatibles / Accesorios | JBE-2160, JBE-2165 |
| Certificado | EN 54-3 |
- Sirena Jade Bird
