Name: QL-GV50CG
Brand: QUECLINK
SKU: 15204
Availability: InStock

QL-GV50CG

722,13 kr.

Additional information

Model	GV50CG
Installation	Hidden under hood
Operating band	LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28
LTE data transmission	LTE-FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
Frequency	850/900/1800/1900 MHz
GSM data transmission	EDGE: (DL)236,8 Kbps/(UL)236,8 KbpsGPRS: (DL)85,6 Kbps/(UL)85,6 Kbps
GNSS type	All-in-one GNSS receiver
Constellations supported	GPS,Beidou
Sensitivity	Cold start: -147dBm Hot start: -155 dBm Tracking: -160 dBm
Location Accuracy (CEP)	Autonomous: < 2m
Dimensions	76(LA) Ã 39(AN) Ã 16(AL) mm
Weight	71.5g
Backup battery	Lithium Polymer, 190 mAh
Working voltage	9V ~ 90V DC
Working temperature	-30â ~ +70â -40â ~ +80â for storage
Message buffer	Up to 10000 messages
Digital Inputs	A (1) positive trigger input for ignition detection
Configurable Inputs	One (1) input configurable for analog input (0 V ~ 16 V) or negative input
Interlocked Digital Output	One (1) digital output with internal latching circuit, open drain, maximum drive current of 150 mA
Cellular antenna	Internal only
GNSS Antenna	Internal only
LED indicators	CEL, GNSS
Micro USB interface	For configuration, updating and debugging
Transmission Protocol	TCP, UDP, SMS
Scheduled report	Report position and status based on preset time intervals, distance, mileage or a combination of these settings
Geo-fence	Geo-fence and parking alarm, supports up to 20 regions
Speed alarm	Flexible speed monitoring, with abnormal speed alarm
Low Battery Alarm	Notifies alarm when battery is low
Trawl alarm	Trailer alarm in off state
Driver behavior	Detect aggressive driver behaviors, including hard braking, hard acceleration, etc.
Collision Detection	Collect crash data for reconstruction and analysis
Remote control	Digital output OTA control
SOS Alarm	Report of alarm message triggered by the emergency button
Virtual Ignition Detection	Based on voltage and accelerometer
Interference Detection	Alarm based on interference detection
